DIP Switch selection – SW1
Pos #1 Pos #2 Pos #3 Pos.#4 Description
For SXGA panel
ON ON ON OFF Sharp LQ181E1LW31
Fujitsu FLC48SXC8V
For WXGA panels
ON OFF OFF OFF Samsung LTA260W2-L01
OFF ON OFF OFF NEC NL12876BC26-21
ON ON OFF OFF Samsung LTA460WS-L03 (Non-tested)*
OFF OFF ON OFF Sharp LQ315T3LZ24 (Non-tested)*
ON OFF ON OFF LG LC420W02-A4 (Non-tested)*
For XGA panel
OFF ON ON OFF LG LM151X2
ON ON OFF ON Sharp LQ150X1LGB1
Sharp LQ150X1LGN2A
Fujitsu FLC38XGC6V-06
ON OFF ON ON NEC NL10276BC12-02
For SVGA panel
OFF OFF ON OFF Sharp LQ104S1DG21
Sharp LQ121S1DG41
OFF ON ON OFF Sharp LQ084S3DG01
ON OFF ON OFF Toshiba LTM12C289
For VGA panel
ON OFF OFF OFF Sharp LQ104V1DG21
Sharp LQ10D368
Sharp LQ104V1DG51
For additonal and recent added panels, see HE-1400 panel support table at http://www.digitalview.com/controllers/csg.php
Pos #5 Pos #6 Pos #7 Description
OFF OFF OFF Reserved
ON OFF OFF Reserved
OFF ON OFF SXGA
ON ON OFF WXGA
OFF OFF ON XGA
ON OFF ON SVGA
OFF ON ON VGA
ON ON ON Reserved
SW1 Pos 8 = Reserved.
DIP switch selection – SW2
Pos. # Function Description
1 Panel pixel format OFF : Double Pixel
ON : Single Pixel
2 LVDS data mapping select
ON : Mapping A (LVDS panel)
OFF : Mapping B (LVDS panel)
Please adjust to get the correct picture. See as Appendix II for details of
mapping A and B.
Set ON for TTL panels.
The most current list can be found the controller solution generator at http://www.digitalview.com/controllers/csg.php
