13
28 NC No connection
29 EB0 Even data bit B0
30 EB1 Even data bit B1
31 EB2 Even data bit B2
32 EB3 Even data bit B3
33 EB4 Even data bit B4
34 EB5 Even data bit B5
35 EB6 Even data bit B6
36 EB7 Even data bit B7
37 GND Ground
38 GND Ground
39 CLK Dot clock
40 NC No connection
CN3 – Panel connector: HIROSE DF20G-50DP-1V (Matching type : DF20A-50DS-1C)
PIN SYMBOL DESCRIPTION
1 GND Ground
2 GND Ground
3 NC No connection
4 NC No connection
5 OR0 Odd data bit R0
6 OR1 Odd data bit R1
7 OR2 Odd data bit R2
8 OR3 Odd data bit R3
9 OR4 Odd data bit R4
10 OR5 Odd data bit R5
11 OR6 Odd data bit R6
12 OR7 Odd data bit R7
13 GND Ground
14 GND Ground
15 NC No connection
16 NC No connection
17 OG0 Odd data bit G0
18 OG1 Odd data bit G1
19 OG2 Odd data bit G2
20 OG3 Odd data bit G3
21 OG4 Odd data bit G4
22 OG5 Odd data bit G5
23 OG6 Odd data bit G6
24 OG7 Odd data bit G7
25 GND Ground
26 GND Ground
27 NC No connection
28 NC No connection
29 OB0 Odd data bit B0
30 OB1 Odd data bit B1
31 OB2 Odd data bit B2
32 OB3 Odd data bit B3
33 OB4 Odd data bit B4
34 OB5 Odd data bit B5
35 OB6 Odd data bit B6
36 OB7 Odd data bit B7
37 GND Ground
38 GND Ground
39 VS Vertical sync
40 CLK Dot clock
41 HS Horizontal sync
42 DE Display enable
43 PWR Power down control signal (5v TTL)
44 VLCD Panel power supply (3,3V/5V) (selected by JA3 & JA6)
45 VLCD Panel power supply (3,3V/5V) (selected by JA3 & JA6)
46 VLCD Panel power supply (3,3V/5V) (selected by JA3 & JA6)
47 NC No connection
48 VLCD12 +12V panel supply (selected by JA3 & JA6)
49 VLCD12 +12V panel supply (selected by JA3 & JA6)
50 VLCD12 +12V panel supply (selected by JA3 & JA6)
