SPECIFICATIONS
Panel compatibility 1366x768, 1280x1024, 1280x768, 1024 x 768, 800x600, 640x480 TFT LVDS
or TTL LCD’s support.
No. of colours Up to 3 x 8 bit providing 16.7 million colours.
Vertical refresh rate SXGA, XGA, SVGA, VGA resolution up to 60Hz.
Dot clock (pixel clock) maximum 135 MHz
Graphics formats Standard SXGA, XGA,SVGA,VGA
Standard input at source - VGA analog (15-pin) standard with automatic detection of :
Digital Separate Sync
Sync-On-Green
Composite Sync
- DVI-D
Controls available - On/Off
- Brightness (inverter)
- OSD menu,
- OSD select
- OSD setting +
- OSD setting -
Control interface - Buttons, Serial Port control
Settings memory Settings are stored in non volatile memory
Language OSD support Graphics OSD icons
VESA DPMS implementation Yes
Plug & Play VESA DDC 1, 2/b compatible
Voltage output for LCD +3.3V , +5V, +12V
Input voltage 12VDC , 5A max +/- 25%, 10W (controller only)
Controller dimensions 107mm x 92mm x 21mm
Storage temperature limits -40
o
C to +85
o
C
Operating temperature limits -40
o
C to +80
o
C**
Coating Silicone resin conformal coating. (MOD) DEF-STAN 59/47 Issue 4 & UL
QMJU2 compliant.
Calculated Mean Time Between Failures In excess of 200,000 hours
** Laboratory certification report available at http://www.digitialview.com/support/downloads/HE-1400_report.pdf .
Overall suitability for usage in critical applications must be independently tested and verified by the user.
NOTES
Please note the following:
• For specific panel setup a sample of an LCD may be required (this will be returned) and a copy of the full technical
specifications for the panel from the manufacturer.
• Relayout and custom development services are available.
