NEXD HDMI Splitter
规格
Input
2EA HDMI Type A
Output
8EA Default (Model: HDMI 208L)
4EA Optional (Model: HDMI 204L)
User Interface
Remote Control IR
RS232 Remote PC/ Device
LED POWER : On / Off
SYNC : Indication of valid input signal
HDMI: Input signal is HDMI or DVI
HDCP: HDCP being used.
EE : EDID Emulation
表示是否使用
Buttons Touch sensors
POWER
可以选择输入
(Input 1 ~ input 2)
可以选择功能
(F1~F4)
Power
+12V/ 3A DC Jack
Firmware
Upgrade
Yes Mini-USB B type connector
HDMI Version
1.3 Deep Color
Higher refresh rate (~120hz)
Colorimetry RGB / YCbCr / xvYCC
CEC
Yes Auto switching
EDID Emulation
EDID Emulation mode supporting
