DIGITECH Audio AC-1727 - Application Example

3
1. SDI IN: This socket connects to an SDI source.
2. POWER LED: This red LED illuminate when the device is connected with power supply.
3. HDMI OUT: This socket connects to an HDMI display.
4. DC IN: Plug the 5V-12V DC power supply into the unit.
 Application Example
