7
INSTALLATION
WIRELESS 5-IN-1 SENSOR
Your wireless 5-IN-1 sensor measures wind speed, wind direction, rainfall, temperature and humidity for you.
It’s fully assembled and calibrated for your easy installation.
BATTERY AND INSTALLATION
Unscrew the battery door at bottom of unit and insert the batteries
according to the +/- polarity indicated.
Screw the battery door compartment on tightly.
Note:
1. Ensure the water tight O-ring is properly aligned in place to
ensure water resistant.
2. The red LED will begin ashing every 12 seconds.
ASSEMBLY THE STAND AND POLE
Step 1
Insert the top side of the pole to the square hole of the
weather sensor.
Note:
Ensure the pole and sensor's indicator align.
Step 2
Place the nut in the hexagon hole on the sensor,
then insert the screw in other side and tighten it
by the screw driver.
Step 3
Insert the other side of the pole to the square
hole of the plastic stand.
To Next Page
