6. CONNECTION DIAGRAM
1. Notebook
Use ONE port
USB-C1 / USB-C2:
PD: 65W Max
5.0V/9.0V/12.0V/15.0V/
3.0A, 20.0 V/3.25A,
PPS: 3.3-21.0V3.25A
1. Notebook
2. Smartphone
Use TWO ports at same
time
USB-C1:
PD: 45W Max
(5.0V3.0A, 9.0V3.0A,
12.0V3.0A,20.0V2.25A),
PPS: 3.3~16.0V/3.0A
USB-C2:
PD: 20W Max
(5.0V3.0A, 9.0V2.22A)
PPS: 3.3~5.9V/3A, 3.3V,
11V/2.2A
