Ribbon installation
(1) Open the top cover by pressing
the open button on both sides.
Then lift the top cover to the maximum
open angle.
(2) Insert ribbon paper core onto ribbon
rewind hub.
(3) Align the notches on the left side and
mount onto the spokes.
(4) Press the open button of print head.
(5) Insert the ribbon paper core onto
ribbon supply hub.
(6) Align the notches on the left side and
mount onto the spokes.
(7) Crossing print head, Stick the ribbon
onto the ribbon rewind paper core and
insert the paper core onto the rewind
smoothly.
(8) Turn the ribbon rewind hub until the
ribbon plastic leader is thoroughly
wound and the black section of the
ribbon covers the print head.
(9) Press down to close the print head, in
accordance with the direction that the
arrows in the picture indicate.
In order to guarantee the print quality,
please check and make sure the print
head is closed completely.
