3
LED Definition
Button Definition
LED Color Status Description
Power
Green On Power is on
Green Blink
●System enters the power save mode.
●System is resetting.
●System is in the process of security setup.
- Off Power is off
Ethernet
Green On
The device is connecting to other devices via the Ethernet
interface but not communicating with them.
Green Blink
The device is receiving or transmitting data via the Ethernet
interface.
- Off
The device is not connecting to other devices via the Ethernet
interface.
Data
Green/
Red
On
The device has connected to the power line network. The Data
LED color will vary according to the physical rate.
●Green: Link Rate > 40 Mbps
●Orange: 20 Mbps< Link Rate <40 Mbps
●Red: Link Rate< 20 Mbps
Red Blink
When the device is scanning other PLC devices, the Data
indicator blink quickly.
- Off
The adapter has not found any other compatible power line
devices that use the same encryption key.
Button Description
Reset Reset to factory default
Security
Press security button during 1~3 seconds Join a another HomePlugAV network
Press security button more than 10 seconds Set its security to random value
