8
2.2.2 After the battery installation and connection done:
Check if BAT+ to N & N to BAT- voltages are correct with multimeter or other
equipments. Install the cover if the voltages are correct.
NOTE: Battery “+” “-” poles cannot be reversed, also cannot short the battery
“+” “-” poles, otherwise batteries would be damaged or other
accidents would happen. Don’t touch the battery “+” “-” poles at the
same time. It’s better only single man make the operation.
3. Battery pack accessories
A complete of 6-10kVA UPS battery pack includes below accessories.
No.
Name
Specification
PCS
1
Cable 1#
Black wire 1015 10AWG 101mm 250TC*2
14
2 Cable 2# Black wire 1015 10AWG 250mm 250TC*2 1
3
Cable 3#
Black wire 1015 10AWG 420mm 250TC*2
1
4
Cable 4#
Black wire 1015 10AWG 600mm 250TC+OI5.5-5
1
5
Cable 5#
Black wire 1015 10AWG 650mm 250TC*2
2
6 Cable 6#
4wires black 1015 12AWG 150mm*2/200mm*2
OI14-5+P30*4
1
7 Cable 7# Red wire 1015 10AWG 550mm 250TC+OI5.5-5 1
8 Cable 8#
4wires Red 1015 12AWG 150mm*2/200mm*2
OI14-5+P30*4
1
9 Cable 9#
4wires Yellow 1015 12AWG 150mm*2/200mm*2
OI14-5+P30*4
1
10 Cable 10#
2wires black 1015 10AWG 410/100mm*2
250TC*2+BN8+ OI5.5-5
1
11 Breaker
IELHK111-71333-1-V 3P 50A/300Vdc 2KA AIRPAX
UL certified
1
12
Battery
Pack
W443*H131*D585mm 1
