1.4 External Component Description
Upper Panel
The upper panel of the Switch consists of a series of LED
indicators
LED indicators:
The LED Indicators will allow you to monitor, diagnose and
troubleshoot any potential problem with the Switch, connection
or attached devices.
The following chart shows the LED indicators of the Switch along
with explanation of each indicator.
LED Indicator
Faceplate
Marker
Status Indication
Power Indicator Power
Off Power Off.
Solid
green
Power On.
10/100 BASE-T
adaptive
Ethernet port
indicators
(1-8)
Link/Act
Off Power Off.
Solid
green
Power On.
Blinking
The port is
transmitting or
receiving data.
