3
2. Technical Features
Number of ports 8 x 10/100/1000Mbps
Power cord
Type-F grounding plug (CEE 7/4) to
IEC C13 cold-device socket
Operating temperature 0°C to 40°C
Operating humidity 20% - 85% (non-condensing)
Storage temperature -10°C to 70°C
Weight 0.95 kg
Uplink ports 2 x SFP 1000Mbps
Auto-negotiation Auto MDI/MDIX
Backplane bandwidth 20 Gbps
Forwarding capacity 14.88 Mpps
MAC addresses 4K
Operating voltage
100 - 240 V AC, 50/60 Hz, integrated power
supply, (IEC C13 IEC plug)
Fan design Fanless
Standards and
protocols
IEEE802.3 10Base-T Ethernet standard
IEEE802.3u 100Base-TX Fast Ethernet standard
IEEE802.3ab 1000Base-T Ethernet standard
IEEE802.3z Gigabit Ethernet (fiber)
IEEE802.3x Full duplex flow control and
Backpressure Half duplex flow control
IEEE802.3az Energy Efficient Ethernet (EEE)
LED Indicators Power, Link/Act
Casing Metal
Installation Rack mounting
