5
Blink: Indicates that the Switch is actively
sending or Receiving data over that port.
5.2 Rear Panel
The rear panel of a switch shows the AC power interface. The
power input ranges from 100 v AC to 240V AC at 50/60 Hz.
Power Socket
This is an AC power socket, connect the negative plug of the
power cord to this interface, and connect the positive plug to
the AC power supply.
Grounding Column
It is located to the left of the power interface. Please use wire
grounding to prevent lightning strike.
6. Installation the Switch
6.1 Matters needing attention
Please follow the following instructions in avoid of incorrect
installation causing device damage and security threat:
Before cleaning the switch, unplug the power plug of the
switch first. Do not clean the switch with wet cloth or liquid
To Next Page
