6. Overview
6.1 Transmitter Unit
1. HDMI in
Connect source devices, like with
a computer or other devices with
HDMI, the HDMI in also supports
5V power if the source devices
has HDMI with a 5V output
2. Button
Short press: start to cast
Long press: long press up to 10
seconds for factory reset
2. LED
To display different statue
3. Micro USB
For power supply
Remark: if the source device has a HDMI with 5V power output, then
there is no need to connect an USB cable for power.
LED indicator of the
Transmitter Unit
Description
Static red
Transmitter Unit system is
booting on
Flashing red
Transmitter Unit is searching for
Receiver Unit
Flashing blue
Waiting for connection
