DB01B DIME
®
CRY BABY
®
FROM HELL 3
1 FOOTSWITCH toggles effect on/bypass (green LED indicates on)
2 VOL knob controls amount of gain added by BOOST switch
3 VARIABLE Q knob controls the sharpness of the DB01’s bandpass
4 FINE TUNE knob shapes tone of toe-down position
5 BOOST switch increases output as set by the VOLUME knob (indicated by red LED)
6 RANGE SELECTOR determines frequency center of WAH WAH
EXTERNAL CONTROLS
2
5
6
1
43
