CAUTION: Disconnect all power coming to heater at
main service panel before wiring or servicing.
Reectors should be cleaned periodically. A mild soap and
water solution or ne cleaning powder is best although more
drastic means may be required if reectors are badly soiled
by chemical or other deposits. The reector is aluminum.
DO NOT use alkali cleaners. Mild non-alkaline cleaners,
such as used for scouring kitchen sinks, may be used. Re-
ectors are replaceable and may be purchased from Dim-
plex.
Maintenance
Model
Electrical Dimensions
Weight
(kg/lbs.)
Watts Volts BTU
Heated Length
(mm/in)
Overall Length
(mm/in)
KRR3184C121 1800 208 6142 546 / 21.5 772 / 30.4 6.3 / 14
KRR3184C131 1800 240 6142 546 / 21.5 772 / 30.4 6.3 / 14
KRR3184C181 1800 600 6142 546 / 21.5 772 / 30.4 6.3 / 14
KRR4304C121 3000 208 10236 953 / 37.5 1178 / 46.4 7.2 / 16
KRR4304C131 3000 240 10236 953 / 37.5 1178 / 46.4 7.2 / 16
KRR4304C181 3000 600 10236 953 / 37.5 1178 / 46.4 7.2 / 16
KRR5424C121 4200 208 14330 1370 / 53 1550 / 61 7.7 / 17
KRR5424C131 4200 240 14330 1370 / 53 1550 / 61 7.7 / 17
KRR5424C181 4200 600 14330 1370 / 53 1550 / 61 7.7 / 17
KRR6504C131 5000 240 17060 1603 / 63.1 1867 / 73.5 9.9 / 22
KRR6504C181 5000 600 17060 1603 / 63.1 1867 / 73.5 9.9 / 22
Operation
KRR radiant heaters are built to operate at 40 watts per sq.
inch on the element sheath. If full radiation intensity is not
required continually when operating, an EIC input controller
may be used to regulate heater output. Magnetic contactors
must be used with all input contorller when radiant heater
loads exceed the capacity of the controller, or load is three
phase.
Warranty
The Manufacturer warrants the heater and components of the enclosed product
against any defect in material or workmanship for a period of one year from
the date of purchase. In full satisfaction of any claims under this Warranty the
Manufacturer will repair or replace without charge, in its factory or in the eld as it
alone may decide, any parts which in its opinion are defective.
The Manufacturer shall not be responsible for any transportation or shipping
costs in relation to such repair or replacement except as specically assumed
by it. Misuse of this product or repairs by persons other than the Manufacturer’s
authorized personnel without the Manufacturer’s written approval, will void this
Warranty.
This Warranty is in lieu of all other warranties or conditions whether express or
implied including but not limited to those of merchantability or tness for purpose
and shall constitute the sole remedy of the Purchaser and the sole liability of the
Manufacturer in respect of the sale of the product, whether in the nature of breach
or breach of fundamental term, or of negligence or otherwise.
The Manufacturer shall not be liable for any special, indirect or consequential
damages or for any damages resulting from removal or replacement of a linear
convector subject to warranty claim without the Manufacturer’s authorization.
This Warranty is transferable by the original consumer purchaser of the product.
Any claims under this Warranty must be submitted in writing to the Service
Manager, Dimplex North America Ltd., 1367 Industrial Rd., Cambridge, Ontario
N1R 7G8, Canada.
