3
L1 L2 or N
GND
L1
L2 or N
Line
L1
L2 or N
Ground
Line
RIGHT SIDE POWER CONNECTION
L1
L2 or N
Ground
WITH SINGLE POLE THERMOSTAT
For Right hand side connection use same logic
L1
L2 or N
Ground
WITH DOUBLE POLE THERMOSTAT
For Left hand side connection use same logic
Load
Ground
!
NOTE: When control accessories are installed, use wiring diagram supplied with the accessory. Following are examples of wiring diagrams with thermostat.
CONNECTING MULTIPLE LINEAR CONVECTORS TOGETHER
In keeping with our policy of continuous product improvement, we reserve the right to make changes without notice.
© 2011 Dimplex North America Limited
1367 Industrial Road Cambridge ON Canada N1R 7G8
1-888-346-7539 www.dimplex.com
WIRING INSTRUCTIONS
Do not bypass or eliminate thermal cutout from the circuit.
Check tightness of all electrical connections and wire nuts.
Grounding connection is required.
LEGEND:
Thermal cutout Heating element
Wire nut connection Ground
Thermal cutout
Nameplate
Ground
Heating Element
FACTORY WIRING
Wire nut connection
LEFT SIDE POWER CONNECTION
