Quick Reference Instructions
3. Domestic hot water preparation
WPM 2006 plus
WPM 2006 R
WPM 2007 plus
WPM 2007 R
How to set the domestic hot water temperature and the hot water block:
ESC
Jump back to the standard display.
Menue
Confirm the selection of the menu item Settings.
Jump to the menu to modify Settings.
Keep pressed
for 3 seconds
Briefly touch
Keep pressed
for 2 seconds
Press the key several times to select the menu item Domestic hot water.Briefly touch
Confirm selection of the menu item Domestic hot water. Briefly touch
Confirm selection of the menu item Hot water set temp. Briefly touch
Increase or lower the hot water set temperature as required.Briefly touch
or
Confirm the set value. Briefly touch
Select the menu item Hot water block. Briefly touch
Confirm selection of the menu item Hot water block. Briefly touch
Jump to the setting to start the Hot water block (Time). Briefly touch
Increase or lower the setting as required. Briefly touch
or
Jump to the other settings until the cursor flashes in the upper corner.
Example: Time 1: 06:00-22:00 will block domestic hot water preparation from 6:00 am to 10:00 pm.
Briefly touch
repeatedly
Select the menu item Hot water block (Mo-Su). Briefly touch
Jump to the individual weekdays from Monday to Sunday.
Briefly touch
repeatedly
Select one or both shut-off times per weekday and confirm by pressing the Enter key:
N: No shut-off time active
T1: Time 1 active as shut-off time
T2: Time 2 active as shut-off time
Y: Time 1 and Time 2 active as shut-off times
Example: SA: N and SU: N will prevent hot water block at weekends.
Briefly touch
or
How to return to the standard screen
and what to do if you have any problems making settings:
Briefly touch
