8 Menu Structure
8.1 Settings
All user settings are made in the “Settings” menu item.
The following table shows not only the menu structure and
explanations in the right-hand column, but also the
corresponding setting ranges. Values in bold print indicate the
factory settings.
You can access the settings menu by:
Pressing the button (MENUE) for approx. 5 seconds
Confirming the settings menu item with the ENTER button.
NOTE
Dynamic menus
The following contains a description of the complete menu. During start-
up, the regulatory functions and the menu structure are adjusted to the
specific system. Non-relevant menu items are then hidden according to
these settings.
Example: Settings for DHW preparation can only be made if the “DHW
preparation” menu item is configured with “Yes” in the preconfiguration.
Abbreviations:
HG2 = 2nd heat generator (e.g. boiler)
System-specific parameters Setting range
Menu for setting the time. An automatic changeover from daylight
saving time (summer) to winter time can be selected.
International 24 h
display
Level for setting operating modes
Selects the operating mode
It is also possible to make changes directly using the modus
button.
Cooling
Summer
Auto
Party
Vacation
HG2
Duration of party mode in hours
After the set period has elapsed, the system returns automatically
back to automatic operation again.
0
... 4 ...
72
Duration of vacation mode in days
After the set period has elapsed, the system returns automatically
back to automatic operation again.
0
... 15 ...
150
Settings for heating circuit 1
Sets the desired room set temperature when room temperature
regulation is selected
15.0 °C
... 20.0 °C ...
30.0 °C
Settings to lower the heating characteristic curve of heating
circuit 1
Sets the time during which the temperature in heating circuit 1 is to
be lowered
00:00
...
23:59
Sets the temperature value by which the heating characteristic
curve of heating circuit 1 is to be lowered when the temperature is
lowered
0 K
...
19 K
For each day of the week, it is possible to select whether Time1,
Time2, no time or both times are to be active when the
temperature is lowered. Operations to lower the temperature that
exceed a week day are activated or deactivated at the end of each
day accordingly.
N
T1
T2
Y
Settings to raise the heating characteristic curve of heating circuit
1
Sets the time during which the temperature in heating circuit 1 is to
be raised.
00:00
...
23:59
Sets the temperature value by which the heating characteristic
curve of heating circuit is to be raised when the temperature is
raised.
0 K
...
19 K
