Dimplex WPM 2007 R User Manual

1. Key assignment
Change the operating mode by pushing the key once or repeatedly:
The filled square in the upper right corner of the display indicates the current operating mode.
Symbol Operating mode Denotation
Auto
Fully automatic control of the entire heat pump
heating system
Vacation
Temperature lowering and hot water block
for an adjustable time period (in days)
Party
For overriding programmed temperature lowering
for an adjustable time period (in hours)
Heat generator 2
Heat pump blocking;
Heating and domestic hot water preparation through the second
heat source (e.g. oil heater) or the electric heating elements
Summer
Domestic hot water and swimming pool water preparation;
Heating operation blocked
Cooling
Cooling operation cannot be activated on all
heat pumps
The heat pump manager is operated using 6 keys:
Modus
Confirm changes to settings (Enter key).
Press the key once to increase the heating temperature by 1 °C.
The indicator bar will move to the right.
Press the key once to reduce the heating temperature by 1 °C.
The indicator bar will move to the left.
2. Settings menus
Jump to the menu to modify Settings.
Jump to other setting options.
Confirm the menu item Settings to go to the submenus.
Briefly touch
Briefly touch
Briefly touch
Briefly touch
Keep pressed
for 2 seconds
Briefly touch
Briefly touch
Keep pressed
for 1 second
Jump back to a higher menu level.
How to adapt the settings to your requirements:
Menue
ESC
ESC
Jump back to a higher menu level.Briefly touch
Keep pressed
for 3 seconds
Keep pressed
for 5 seconds
Activate and deactivate the keylock.
Jump back to the standard display.
Menue
Jump to the menu to modify Settings.
Keep pressed
for 2 seconds
When the key is pressed, the selected operating mode will be shown as text in the display.
The selected operating mode will be activated after approx. 10 seconds.
or
Quick Reference Instructions
WPM 2006 plus
WPM 2006 R
WPM 2007 plus
WPM 2007 R
Note: These quick reference instructions do not replace the enclosed operating instructions, which can also be downloaded from the Internet.
