9
© 2003 Directed Electronics, Inc
REM GNDBATT
20A
FUSE
SPEAKER OUTPUT
LR
BRIDGED
FIGURE 2—AMPLIFIER CONNECTIONS 200/2 300/2 REAR
1
2
4
3
5
REM GNDBATT
25A
FUSE
LR
BRIDGED
SPEAKER
OUTPUT
FRONT
REAR
FIGURE 2—AMPLIFIER CONNECTIONS 250/4 REAR
1
2
4
3
5
