10
UNIVERSAL MOUNTING BRACKET.
The bracket is designed to allow for many different mount-
ing techniques. It can be bent or cut and mounted in
several different orientations to facilitate the proper place-
ment and orientation of the Sirius radio being installed.
One common application is to pull a dash panel or console
and secure the “fingers” of the bracket with self tapping
screws behind the panel after bending or cutting it to place
the Sirius radio in the chosen location and orientation. The
elongated holes on the fingers can be used to shorten or
lengthen the distance it protrudes from behind the panel.
After securing the Universal Mounting Bracket replace
the panel removed earlier and check that there is enough
clearance for the bracket and that it does not interfere with
the fit of the vehicles panel.
In some cases the Sirius radio cradle can be mounted
directly to the Universal Mounting Bracket with the sup-
plied screws. In other cases it may be necessary to attach
the swivel base to the Universal Mounting Bracket and then
the Sirius radio cradle to the swivel base to accommodate
proper positioning and orientation of the radio. Once the
appropriate orientation of the Swivel Bracket has been
determined, tighten the center screw to secure it from
moving. Be careful not to over-tighten the screw as it can
damage the Swivel Bracket.
