SSppeecciiffiiccaattiioonnss
NNOOTTEE::
Specifications and design are subject to change without notice.
SSyysstteemm
Laser Semiconductor laser
Signal Formats NTSC, PAL
AAuuddiioo CChhaarraacctteerriissttiiccss
Frequency Response
DVD Video (PCM@ 96kHz) 20 Hz - 40 kHz ± 1dB
DVD Video (PCM@ 48kHz) 20 Hz - 20 kHz ± 1dB
CD 20 Hz - 20 kHz ± 1dB
Signal-to-Noise Ratio 90dB
Harmonic Distortion 0.01%
Dynamic Range
DVD Video 95dB
CD 95dB
OOuuttppuuttss ((AA//VV SSwwiittcchhbbooxx))
Audio (phono jacks) 2 Vrms
Video (phono jack) 1 V p-p @75 ohms
IInnppuuttss ((AA//VV SSwwiittcchhbbooxx))
Audio (phono jacks) 2 Vrms
Video (phono jack) 1 V p-p
GGeenneerraall
Power Requirements 14.4 VDC, 3.35 amps
Power Consumption 42.6 watts
Dimensions
345 mm x 65 mm x 282 mm
(length/height/width)
13.6 in. x 2.6 in. x 11.1 in.
(length/height/width)
Mass 2.3 kg 5 lbs
Operating Temperature 0°–50°C 32°–120°F
Operating Humidity 10% to 90%
