Installation
Choose Your Setup
S-Video & A/V Audio Connection (Best Quality)
Using the S-Video cable, connect one end to the S-VIDEO output jack on the DIRECTV Receiver
and the other end to the S-Video input jack on the TV.
Using the A/V cable, connect the white and red plugs from one end of the A/V cable to the AUDIO L
(white) and R (red) jacks on the back of the DIRECTV Receiver. Connect the plugs from other end of
the A/V cable to the corresponding audio input jacks on your TV or VCR. Do not plug the video (yel-
low) into either the DIRECTV Receiver or the TV.
If hooking up a VCR, use another A/V cable to connect the white and red plugs from one end of the
A/V cable to the audio L (white) and R (red) and video (yellow) output jacks on the back of the VCR.
Connect the plugs from the other end of the A/V cable to the corresponding input jacks on your TV.
Then, use another A/V cable to connect the white and red plugs from one end of the A/V cable to the
AUDIO L (white) and R (red) and VIDEO (yellow) OUTPUT jacks on the back of the DIRECTV
Receiver. Connect the plugs from other end of the A/V cable to the corresponding input jacks on your
VCR.
Now, continue on page 64, “Connecting Your DIRECTV Receiver to Your Telephone Line.”
