TOOLS REQUIRED
1
• Drill – for drilling holes in the back of the sleeper
1. 3/8” drill bit
2. 1/4” drill bit
• Riv Nut Tool – used to secure riv nuts into holes drilled in back of sleeper.
*Can be purchased separately.
• Impact Gun
1. 3/8” hex key used with Riv-Nut tool
2. 7/16” socket for attaching rear mount to sleeper using 1/4”-20 bolts
provided in rear mount box
• Wrenches for use with Riv Nut tool
1. 1/2” end wrench
2. 3/4” end wrench
• 1/2” socket
• 3/8” socket
• 1-1/8” hole saw or step bit used for drilling hole in sleeper to run coaxial
into cab when there is no factory-installed cable entry point
• 1/2” Flex-tubing for coaxial cables at entry-point to sleeper
• Silicone Sealant
• Dielectric Grease
A
B
C
D
E
F
G
H
I
A
G
A
F
3/8”
D
2. 3/4”
1. 3/8”
1. 1/2”
C
I
1. 3/8”
2. 1/4”
4
B
C
2. 7/16”
C
E
1/2”
H
