This document describes the Discovery™ World Furniture 2114/2814/0214 Mission Stair Stepper Bunk Bed, providing assembly instructions, safety warnings, and product specifications.

Function Description:

The Discovery™ Mission Stair Stepper Bunk Bed is a multi-functional furniture piece designed to provide sleeping arrangements for children, featuring a bunk bed structure with an integrated stair stepper and storage drawers. The design prioritizes safety and durability, meeting various consumer safety standards. The stair stepper design offers an alternative to traditional ladders, potentially enhancing safety and ease of access to the upper bunk, especially for younger children. The integrated drawers provide convenient storage solutions, making the bunk bed a space-efficient option for children's rooms. The bed can be configured with the stair stepper on either the left or right side, offering flexibility in room arrangement. An optional full extension kit with a pre-assembled 3-drawer unit can be slid under the bunk for additional storage.

Important Technical Specifications:

Model Numbers: 2114/2814/0214 Mission Stair Stepper Bunk Bed.
Compliance: Designed and manufactured to comply with ASTM F 1427-13 "Standard Consumer Safety Specification for Bunk Beds," Code of Federal Regulations (CFR) 1213 "Safety Standards for Entrapment Hazards in Bunk Beds," and (CFR) 1513 "Requirements for Bunk Beds."
Mattress and Foundation Size (Upper Bunk):
- Length: 74-75 inches
- Width: 37 ½-38 ½ inches
Mattress and Foundation Thickness (Combined): Must not exceed 9 inches.
Mattress Surface Position: Must be at least 5 inches (127 mm) below the upper edge of guardrails.
Age Restriction (Upper Bunk): Not for children under 6 years of age.
Occupancy (Upper Bunk): Prohibit more than one person on the upper bunk.
Materials: The bed components appear to be constructed from wood, with slats providing mattress support.
Tools Required for Assembly: Number 3 Phillips screwdriver, Allen wrench, Allen bit.
Patent Information: Patent # US 7,832,031 B1.

Usage Features:

Stair Stepper Design: Provides a safer and more stable alternative to a ladder for accessing the upper bunk. The stair stepper includes integrated drawers for storage.
Configurable Stair Stepper: The stair stepper unit can be installed on either the left or right side of the bunk bed to suit room layout preferences. Instructions are provided for both configurations.
Integrated Storage: The stair stepper unit features multiple drawers for storing clothes, toys, or other items. An optional pre-assembled 3-drawer unit can be added under the bunk for extended storage.
Guardrails: The upper bunk is equipped with guardrails on both long sides to prevent falls. If the bunk bed is placed next to a wall, the full-length guardrail should be positioned against the wall to prevent entrapment.
Slat Kit System: The bed uses a slat kit for mattress support, designed for easy installation, starting flush with the cleat.
Magazine Rack: The bunk bed includes a magazine rack, which can be installed on either side depending on the stair stepper configuration.
Safety Labels: Warning labels are affixed to the upper bunk end structure and carton and should not be removed.
Nightlight Recommendation: The use of a nightlight is suggested for added safety for children using the upper bunk.

Maintenance Features:

Periodic Checks: Users are advised to periodically check and ensure that guardrails, the ladder (stair stepper in this case), and other components are in their proper position, free from damage, and that all connectors are tight.
Replacement Parts: Replacement parts, including additional guardrails, can be obtained from any Discovery dealer or directly from Discovery World Furniture.
Limited Lifetime Warranty: Discovery World Furniture offers a warranty for replacement parts:
- First Year: Any component part will be replaced free of charge via UPS freight collect for 1 full year.
- Lifetime: Any component part will be replaced for 50% of the then prevailing retail price plus freight for the lifetime of the product, unless the product has been discontinued from their line.
Prohibited Items: The use of water or sleep flotation mattresses is prohibited.
Strangulation Hazard Warning: Users are warned never to attach or hang items not designed for use with the bed (e.g., hooks, belts, jump ropes) to any part of the bunk bed.
General Care: The manual implies that proper assembly and adherence to safety guidelines are key to maintaining the bed's integrity and safety.
