02
Use the clockwork-inspired wrench to tighten the bolts
– no other tools required!
ImageTurn the wrench clockwise to tighten bolts.
ImageTurn the wrench counterclockwise to loosen bolts.
Line up each foot (x2) to the bottom body plate and attach with the bolts.
Bottom Body Plate
x1
Bolt
x4
Foot
x2
01
01
02
03
HOW TO BUILD
ASSEMBLY
tighten loosen
IMPORTANT: Do not overtighten or force the bolts. You could
break the bolts or the robot!
