07
ASSEMBLY
07
With the face markings facing out, slide the face plate into the grooves in the front of
the side head plates. With the hole at the top, slide the back head plate into the
grooves in the back of the side head plates. Place the top head plate on top and attach
with the bolts. After the bolts are tightened, place the wrench in the hole on the top
head plate for a pretend clockwork key.
Face Plate
x1
Top Head Plate
x1
Wrench
x1
Bolt
x4
Back Head Plate
x1
To Next Page
