Back Panel
Product Overview
• 07 •
R-NZ
HDMI
AV OUT
ANTENNA
5V 0.5Amax
USB
13V/18V 0.45Amax
LNB IN
12V 2A
ETHERNET
for Satellite
S8300
DIGITAL SATELLITE RECORDER
Front Panel
07
06
02
05
04
01 03
01. LNB IN
Satellite Cable Input.
02. ETHERNET
Wired Internet Connectivity.
03. USB
Firmware Update & HDD Connection.
04. HDMI
High Definition Output for HDTV.
05. AV OUT
Audio/Video Output.
06. DC 12V
Connect the Power Adapter.
07. INTERNAL WIFI
Wireless Internet Connectivity.
08. DETAILS
Website, Phone Number, Address.
01
01. DISPLAY
Displays Channel, Function.
02. FUNCTIONS
Power, Navigation Arrows.
08
02
