1.
Labeling Your Cables
125
HOME VIDEO
NETWORK
125
HOME VIDEO
NETWORK
Use the labels provided to complete this step. Do not remove any cables from the receiver being
replaced until Step 2.
a.
Attach the blue label to the cable
connected to the “Home Video
Network” port.
Home Video
Network
Home Video
Network
b.
You will be using either an HDMI
cable, YPbPr cables, or RCA cables
as your audio/video connection.
Attach the black label to the cable
connected to the“HDMI” port or
attach the orange lable to the
cables connected to the RCA ports
or attach the red label to the cables
connected to the YPbPr ports.
RCA
COMPOSITE
RCA
COMPOSITE
Ccomponent
Ccomponent
YPbPr
YPbPr
To Next Page
