6
OA_Humidity – Current outside air humidity.
Coil_Temp – Current cooling coil exit temperature.
Preheat_Temp – Current preheat exit temperature.
DA_Temp – Current discharge air temperature (if more than one
discharge sensor is used this will be an averaged value).
DA_Humidity – Current discharge humidity (if more than one
discharge sensor is used this will be an averaged value).
DA_Airflow – Current discharge airflow CFM (only available if airflow
monitoring and control is available).
Cooling_Command – Current cooling demand (0% - 100%).
Heat_Command – Current preheat demand (0% - 100%).
Humidity_Command – Current humidification demand (0% - 100%).
Reheat_Command – Current reheat demand (0% - 100%).
Alarms (alarm menu is only visible if an alarm is present)
Dirty_Prefilter – Dirty pre-filter indication (only available if the unit
has dirty pre-filter monitoring as an option).
Dirty_Final_Fltr – Dirty final filter indication (only available if the unit
has dirty final filter monitoring as an option).
Low_Temp_Alarm – Low temperature lockout alarm. This is an
indication that the unit was discharging air colder than the “Low Temp
Alarm” setting in the “Config” menu for greater than “Low Temp Time”
minutes. Check the burner for proper operation.
OA_Temp_Sensor – Outside temperature sensor alarm status.
Enumerated “no-fault/open/short”. Check sensor wiring.
OA_Hum_Sensor – Outside humidity sensor alarm status.
Enumerated “no-fault/open/short”. Check sensor wiring.
Coil_Sensor – Coil exit sensor alarm status. Enumerated “no-
fault/open/short”. Check sensor wiring.
