5
Menu Tree
Scrolling Display
Discharge_Temp – Current discharge temperature at the unit
discharge (if more than one discharge sensor is used this will be an
averaged value of the sensors).
Discharge_Humidity – Current discharge humidity at the unit
discharge (if more than one discharge sensor is used this will be an
averaged value of the sensors).
Discharge_Airflow – If the unit is equipped with airflow monitoring
and control, this will reflect the discharge CFM of the unit (only visible
when airflow monitoring and control is available).
Quick Access
Fan_Command – This is accessed by pressing the “up arrow” from
the main screen and is used to turn the unit ON and OFF.
Set Points
Temp_Set_Point – Discharge Temperature Set Point.
Hum_Set_Point – Discharge Humidity Set Point
CFM_Set_Point – Discharge Airflow CFM Set Point (only available if
airflow monitoring and control is available).
Manual_VFD_Speed – Manual VFD Speed Percent Set Point. This
will override the CFM Set Point (above) and force the VFD to run at a
constant, pre-set speed. For automatic control enter ‘null’ value.
Burner_1_Reset – Preheat Burner reset command for use during a
burner lockout alarm. This is an “on/_on_” toggle selectable via the “up
arrow” button.
Burner_2_Reset – Reheat Burner reset command for use during a
burner lockout alarm. This is an “on/_on_” toggle selectable via the “up
arrow” button.
Status
OA_Temp – Current outside air temperature.
