SECTION 9 (cont’d)
Main Frame…………………………………………….. 18
Kohler Command 20 Hp Engine……………………… 20
Kohler Command 22 Hp Engine……………………… 22
Kohler Command 25 Hp Engine……………………… 24
Seat……………………………………………………… 26
Electrical System………………………………………
.
28
42" Mower Deck………………………………………
…
30
50" Mower Deck………………………………………
…
32
60" Mower Deck………………………………………
…
34
Hubs and Belts…………………………………………. 36
Fenders and Covers……………………………………. 38
T Gear Box……………………………………………… 40
Foot Pedal………………………………………………. 42
Tires and Wheels………………………………………. 44
Hydraulic Wheel Motors………………………………. 46
Throttle Assembly……………………………………… 48
Fuel Tank……………………………………………….. 48
Transmission and Drive………………………………
…
50
Transmission Drive Linkage…………………………… 52
Parking Brake…………………………………………
…
54
Hydraulic System………………………………………
.
56
SECTION 10
Index…………………………………………………….. 58
Notes……………………………………………………. 59
