DJI Avata 2 User Manual

3. Put on the goggles after the devices are powered on.

4. Rotate the headband adjustment knob on the battery compartment to adjust the length of

the headband. Rotate clockwise to tighten the headband and counterclockwise to loosen the

headband. It is recommended to wear the goggles with the battery compartment placed on

the upper back part of the head to avoid it sliding down.

Getting Clear Vision

Rotate the knobs on the bottom of the goggles to adjust the diopters if your vision is in the

range of -6.0D to +2.0D. The screen in the goggles will display the diopter value when rotating.

1. Rotate both the knobs in the direction as shown to unlock them. Once unlocked, the knobs

will pop out.

2. Slide left and right to adjust the distance between the lenses until the image is properly

aligned.

56~72 mm56~72 mm

Other manuals for dji AVATA 2

Questions and Answers:

Need help?

Do you have a question about the dji AVATA 2 and is the answer not in the manual?

General

Type	Quadcopter
Product color	Black
Construction type	Ready-to-fly (RTF)
Suitable for outdoor use	Yes
Maximum speed	27 m/s
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Number of rotors	4 rotors
Bluetooth version	5.0
Maximum flight time	23 min
Maximum flight altitude	5000 m
Maximum weight capacity	- kg
Maximum wind resistance	10.7 m/s
Horizontal hover accuracy	0.3 m
Maximum operating distance	13000 m
Megapixel	12 MP
Video color modes	D-Log, Normal
Video resolutions	1440 x 1080, 1920 x 1080, 2688 x 1512, 2688 x 2016, 3840 x 2160 pixels
Maximum frame rate	60 fps
Optical sensor size	1/1.3 \
Camera shutter speed	Video: 1/8000-1/30, Photo: 1/8000-1/50 s
Mechanical tilt range	-95 - 90 °
Normal focusing range	0.6 - ∞ m
Supported file systems	exFAT
Angular vibration range	-0.01 - 0.01 °
Image formats supported	JPEG
Maximum aperture number	2.8
Video formats supported	H.264, H.265, MP4
Maximum image resolution	4000 x 3000 pixels
Maximum video resolution	3840 x 2880 pixels
Field of view (FOV) angle	155 °
Bitrate at maximum video resolution	130 Mbit/s
Built-in processor	-
Internal memory	46 GB
Operating frequency	2400 - 2483.5 MHz
Battery voltage	14.76 V
Battery capacity	2150 mAh
Antennas quantity	4
Operating temperature (T-T)	-10 - 40 °C
Equivalent Isotropically Radiated Power (EIRP)	10 dBmW
Package type	Box
Cables included	USB Type-C
