Repair Manual DJI FPV Series
cracked or misshapen, or if there are
any other cosmetic damages.
Lower shell cracked
or misshapen
Perform a visual inspection and
check if the lower shell is obviously
cracked or misshapen, or if there are
any other cosmetic damages.
Replace the remote
controller.
Control sticks not
centered
Check if the drone response
corresponds to the control stick
input.
Use the app to calibrate
the remote controller. If
the issue persists, replace
the remote controller.
Power-on failure
Check if the remote controller can
be powered on after charging.
Replace the remote
controller.
Remote controller
GPS error
Check if the app prompts a “Remote
Controller GPS Error” warning.
Replace the remote
controller.
Linking failure
Check if the firmware of the remote
controller is the latest version. If yes
and the remote controller cannot be
linked with the drone, the remote
controller is malfunctioning.
Replace the remote
controller.
DJI Motion Controller
Common Issue
Inspection Method
Repair Method
Outer shell cracked
or misshapen
Perform visual inspection and check
if the outer shell is obviously cracked
or misshapen, or if there are any
other cosmetic damages.
Replace the DJI Motion
Controller.
Motion Control Not
Working
Check if the app prompts an IMU
error warning.
Replace the DJI Motion
Controller.
Power-on failure
Check if the motion controller can be
powered on after charging.
Replace the DJI Motion
Controller.
Linking failure
Check if the firmware of the motion
controller is the latest version. If yes
and the motion controller cannot be
linked with the drone, the motion
controller is malfunctioning.
Replace the DJI Motion
Controller.
Goggles
Common Issue
Inspection Method
Repair Method
Outer shell cracked
or misshapen
Perform visual inspection and check
if the outer shell is obviously cracked
or misshapen, or if there are any
other cosmetic damages.
Replace the goggles.

dji FPV Series Specifications

General

Operating Frequency	2.400-2.4835 GHz, 5.725-5.850 GHz
Max Video Bitrate	120 Mbps
Photo Format	JPEG
Internal Storage	No
Battery Capacity	2000 mAh
Maximum Speed	140 km/h (87 mph) in Sport Mode
Max Flight Time	20 minutes
Camera Sensor	1/2.3" CMOS
Video Resolution	4K@50/60fps, 2.7K@50/60/120fps, 1080p@50/60/120fps
Transmission Range	10 km (FCC), 6 km (CE), 6 km (SRRC), 6 km (MIC)
Weight	Approx. 795 g
Max Speed	140 km/h (87 mph) in Sport Mode
Operating Temperature	-10°C to 40°C (14°F to 104°F)
Effective Pixels	12 million
Lens	FOV: 150°; Aperture: f/2.8; Focus Range: 0.6 m to ∞
ISO Range	100-12800
Supported File Formats	exFAT, FAT32
Video Format	MP4 (H.264/MPEG-4 AVC, H.265/HEVC)
Vision System	Downward Vision System
GNSS	GPS + GLONASS
Charging Time	90 minutes
Video Transmission System	DJI O3 Transmission
