Repair Manual DJI FPV Series
Abnormal screen
display
Perform visual inspection and check
if the screen is black out or freezes,
and if the screen is not displayed
completely.
Replace the goggles.
Foam padding
broken or misshapen
Perform visual inspection and check
if the foam padding is obviously
cracked or misshapen, or if there are
any other cosmetic damages.
Replace the foam padding.
Power-on failure
Replace the battery or power cable
and then check if the issue is
resolved.
Replace the goggles.
Linking failure
Check if the firmware of the goggles
is the latest version. If yes and the
goggles cannot be linked with the
drone, the goggles are
malfunctioning.
Replace the goggles.
Battery and Charger
Common Issue
Inspection Method
Repair Method
Battery/charger
outer shell cracked
or misshapen
Perform a visual inspection and
check if there are any other cosmetic
damages such as cracked and
misshapen that may affect normal
use.
Replace the corresponding
defective module.
Battery charging
error
Use a functional battery charging
hub to charge the battery and see if
it can be charged.
Replace the corresponding
defective module.
Discharging error
Install the battery to the drone and
check if the drone can be powered
on.
Replace the corresponding
defective module.
Cable
Common Issue
Inspection Method
Repair Method
Cable damaged
Perform a visual inspection and
check if the cable is damaged.
Replace the cable.
Unable to connect
the mobile phone
Replace the cable and check if the
connection is normal.
Replace the cable.

dji FPV Series Specifications

General

Operating Frequency	2.400-2.4835 GHz, 5.725-5.850 GHz
Max Video Bitrate	120 Mbps
Photo Format	JPEG
Internal Storage	No
Battery Capacity	2000 mAh
Maximum Speed	140 km/h (87 mph) in Sport Mode
Max Flight Time	20 minutes
Camera Sensor	1/2.3" CMOS
Video Resolution	4K@50/60fps, 2.7K@50/60/120fps, 1080p@50/60/120fps
Transmission Range	10 km (FCC), 6 km (CE), 6 km (SRRC), 6 km (MIC)
Weight	Approx. 795 g
Max Speed	140 km/h (87 mph) in Sport Mode
Operating Temperature	-10°C to 40°C (14°F to 104°F)
Effective Pixels	12 million
Lens	FOV: 150°; Aperture: f/2.8; Focus Range: 0.6 m to ∞
ISO Range	100-12800
Supported File Formats	exFAT, FAT32
Video Format	MP4 (H.264/MPEG-4 AVC, H.265/HEVC)
Vision System	Downward Vision System
GNSS	GPS + GLONASS
Charging Time	90 minutes
Video Transmission System	DJI O3 Transmission
