DJI Goggles 2 User Manual
v1.0
Contents
© 2022 DJI All Rights Reserved
23
3. Adjust the diopter of the goggles according to your
needs and lock the knobs.
For example, if you usually wear -6.0 D glasses
and the self-prepared lens is -3.0 D, then you will
need to adjust the diopter of the goggles to -3.0 D
to ensure that the overall diopter is -6.0 D after the
eyeglass frame is installed on the goggles.
< 2.8 mm
4. Install the left and right frames onto the goggles.
When installing, make sure that the mark on the top
of the frame is facing upwards, and the triangular
arrow is aligned with the white dot on the upper
edge of the goggle lens.
L
R
If the installed lens supports astigmatism
correction, do not rotate the knob after the
eyeglass frame is installed. Otherwise, the
astigmatism axis will shift resulting in blurred
vision. Make sure to adjust the diopter of the
goggles before installing the eyeglass frames.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the dji GOGGLES 2 and is the answer not in the manual?

dji GOGGLES 2 Specifications

General IconGeneral
Display TypeMicro-OLED
Resolution1920x1080 per eye
Refresh Rate100 Hz
Field of View51°
Interpupillary Distance56-72 mm
Battery LifeApprox. 2 hours
Screen Size (Single Screen)0.49 inch
Video Recording Max Bitrate50 Mbps
Video FormatMP4
CompatibilityDJI Avata, DJI O3 Air Unit
Adjustable IPDYes
Built-in Diopter AdjustmentYes
Weight290g
ConnectivityBluetooth
Video Recording Frame Rate60fps
Operating Temperature-10°C to 40°C
Latency30 ms
