dji INSPIRE 2 Quick Start Guide

4
EN
10
4
9
8
5
6
1
3
7
2
Remote Controller
The Inspire 2 remote controller features DJI’s LIGHTBRIDGE
TM
technology for a maximum transmission distance
of up to 4.3 mi (7km)*. While ying the aircraft, you have a live HD view directly within the DJI GO
TM
4 app on your
paired device for a precise and responsive ying experience. When in dual remote controller mode, each of the
two remote controllers separately control aircraft and camera and can be up to 328 feet (100m) apart.
The maximum run-time of the remote controller’s LiPo battery is approx. four hours**.
11. Control Dial (Gimbal/FPV/Zoom)
12. Camera Settings Dial
13. Record Button
14. Flight Mode Switch
15. Shutter Button
16. Pause Button
17. Micro USB Port
18. CAN Bus (Extended Port)
19. HDMI A Port (for Video Output)
20. USB Port (for Mobile Device Connection)
21. C1 Button
22. C2 Button
1. Power Button
2. Transformation Switch
3. Return-to-Home (RTH) Button
4. Control Sticks
5. Status LED
6. Battery Level LEDs
7. Power Port
8. Mobile Device Holder
9. Antennas
10. Handle Bar
Folded
Connect your
mobile device
* The remote controller is able to reach its maximum transmission distance (FCC) in a wide open area with no Electro-Magnetic interference, and
at an altitude of about 400 feet (120 meters).
** Maximum run-time is tested without supplying power for the external mobile device.
17 18 19
20
11
14
13
12
1615
2221

dji INSPIRE 2 Specifications

General

Type	Quadcopter
Easy to use	Yes
Product color	Black, Grey
Maximum speed	26 m/s
Frequency band	2.4 - 2.483 / 5.725 - 5.85 GHz
Number of rotors	4 rotors
Integrated sensors	Infrared (IR) sensor
Maximum flight time	27 min
Maximum ascent speed	6 m/s
Maximum descent speed	4 m/s
Maximum weight capacity	- kg
Maximum wind resistance	10 m/s
Vertical hover accuracy	0.5 m
Horizontal hover accuracy	1.5 m
Maximum operating distance	7000 m
Maximum yaw angular velocity	150 °/sec
Maximum pitch angular velocity	300 °/sec
Operating frequency	2400 - 2483, 5725 - 5850 MHz
Maximum device width	170 mm
Built-in processor	-
Operating temperature (T-T)	-20 - 40 °C
Battery voltage	22.8 V
Battery capacity	4280 mAh
Transmitter battery capacity	6000 mAh
Number of batteries supported	2
Number of batteries (transmitter)	1
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Battery weight	515 g
Takeoff weight (max)	4250 g
Weight (including battery)	3440 g
