dji INSPIRE 2 Quick Start Guide

6
EN
Low
High
High
Low
B
A
Using Inspire 2
1. Download the DJI GO 4 App 2. Watch the Tutorial Videos
Search ‘DJI GO 4’ on the App Store or
Google Play and download the app to your
mobile device.
Watch the tutorial videos at www.dji.com or in
the DJI GO 4 app.
DJI GO 4 App Tutorial Videos
First-time activation requires your DJI account and internet connection.
DJI GO 4 app supports iOS 9 (or later) or Android 4.4 (or later).
Only use battery slot A when using one battery to supply power.
Internet
3. Check the Battery Levels and Power on
Press once to check the
battery level.
Press once, again and
hold to turn on/off.
* Provided charger
4. Charge the Batteries
Press the release button and open the corresponding charging port cover.
Insert the Intelligent Flight Battery into the charging port to begin charging.
Charging Time: 1.5 hours* Charging Time: 3 hours*
Power Outlet
100-240V
A
B
B
A
1
2
The Intelligent Flight Battery must be fully charged before using it for the rst time. Make sure to press the release button on the Charging
Hub’s top when removing the fully charged battery.
Only use the ofcial DJI charger and Charging Hub with your Intelligent Flight Battery and remote controller.
When charging is complete, the LED lights on the Intelligent Flight Battery will turn off, and the LED on the Charging Hub will show green.
Power off the remote controller before charging. When charging is complete, the LED lights on the remote controller will turn off.
The Charging Hub will sound a signal when the battery has been fully charged. The sound can be turned on or off by toggling the switch
under the hub.
Press the button on the battery once to check the battery level.
When the temperature is lower than 10℃, press and hold for 3 seconds to heat the battery. The battery will maintain a temperature
between 15-20℃ for approximately 20 minutes. Press and hold 3 seconds again to stop heating the battery.
Pairing batteries is recommended. This can be done inside DJI GO 4 app. Ensure each battery pair is charged and discharged
simultaneously to prolong their service life and for a better ight experience.

dji INSPIRE 2 Specifications

General

Type	Quadcopter
Easy to use	Yes
Product color	Black, Grey
Maximum speed	26 m/s
Frequency band	2.4 - 2.483 / 5.725 - 5.85 GHz
Number of rotors	4 rotors
Integrated sensors	Infrared (IR) sensor
Maximum flight time	27 min
Maximum ascent speed	6 m/s
Maximum descent speed	4 m/s
Maximum weight capacity	- kg
Maximum wind resistance	10 m/s
Vertical hover accuracy	0.5 m
Horizontal hover accuracy	1.5 m
Maximum operating distance	7000 m
Maximum yaw angular velocity	150 °/sec
Maximum pitch angular velocity	300 °/sec
Operating frequency	2400 - 2483, 5725 - 5850 MHz
Maximum device width	170 mm
Built-in processor	-
Operating temperature (T-T)	-20 - 40 °C
Battery voltage	22.8 V
Battery capacity	4280 mAh
Transmitter battery capacity	6000 mAh
Number of batteries supported	2
Number of batteries (transmitter)	1
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward

Weight and Dimensions

Battery weight	515 g
Takeoff weight (max)	4250 g
Weight (including battery)	3440 g
