dji MATRICE 200 series Maintenance Guide

Thecontentissubjecttochange.
Download the latest version from
https://www.dji.com/matrice-200-series
Support Center Contact Info:
http://www.dji.com/support
Checking for worn and loose parts:
1. Checkthatthegimbalprotectioncableisproperlyaffixed to thegimbalframe.
Replaceitwitha0.5mmshinglineifitisdamaged.(Fig.4)
2. Checkthatthelanding gear lockscrewistightenedproperly,and ensure thatthe
landinggearrmlylockswhenconnectedtothedrone.(Fig.5)
3. Checkthatthebatteryreleasebuttonisworkingnormally,andthebatterycanbe
mountedrmly.
4. Checkthepropellerbasescrewsaretightened.Ensurethespringelasticityis good
andnoforeignobjectsarestuckinthespring.
5. Ensurethattheframearmconnectorsarerotatingsmoothly.
6. Keeptheupwardinfraredsensorlenscleanandavoidwearandtear.
7. Checkthefollowingpartsforsignsofwearing:propellers,landinggearsandmotors.
Ifthesepartsseemwornordamaged,pleasecontactyourresellertoscheduleparts
replacements.
8. Landing gears:Checkthedrawnlineonthelandinggearwhenmounted to ensure
ithasbeeninstalled.Todeterminewhetherthe landing gearisproperlymounted,
rmlypulloutthelandinggear.Iftheattemptfails,thisindicatesithasbeenproperly
mounted.
9. Keepthevisionsystemcameralensescleanandavoidscratchingthem.
10. Checkthebatterybuttonisfunctioningnormally.DONOTpressthebuttonwithsharp
objects.
11. Checkthebatterylightwaterproofcoversandmakesurethecovershavenosignsof
comingoff.
12. ChecktheexternalGPScableandconnectortoavoiddamage.
13. Checkthegimbaldampenerstoavoidaging,cracking,orleaking.(Fig.6)
IV. Storage Tips
1. Avoidlayingthedroneonthebatterycompartment,asthiswillcausedamagetothe
visionpositioningsystem.
2. Besuretostoreyourbatteriesinadryplace.
3. DetachtheupwardsinglegimbalandtheGPSmoduleforstorage.
V. Updating Apps and Firmware
Makesureyouareusingthe latest firmwareandappswhenflyingyour M200 Series
drone:
1. Checkthelatestrmwareversioninthereleasenotes:
https://www.dji.com/matrice-200-series/info#downloads
2. DJIPilotappdownloadlink:
http://dl.djicdn.com/djipilot-ofcial.apk
Fig.4
Fig.5
Fig.6
MATRICE is a trademark of DJI.
Copyright © 2017 DJI All Rights Reserved.
Printed in China.

dji MATRICE 200 series Specifications

General

Max Takeoff Weight	6.14 kg
Ingress Protection Rating	IP43
Satellite Systems	GPS/GLONASS
Max Flight Time	38 minutes
Hovering Accuracy	Vertical: ±0.5 m, Horizontal: ±1.5 m
Diagonal Size	650 mm
Charging Temperature Range	5°C to 40°C
Operating Temperature Range	-4°F to 113°F (-20°C to 45°C)
