Transmitter Power
(EIRP)
2.4 GHz
FCC: ≤26 dBm; CE/MIC: ≤20 dBm; SRRC: ≤20 dBm
5.8 GHz
FCC: ≤26 dBm; CE: ≤14 dBm; SRRC: ≤26 dBm
Operating Voltage
1800mA @ 3.83V (when charging the mobile device)
Supported Mobile Device
Size
Thickness supported: 6.5 - 8.5 mm, Max length: 160 mm
Supported USB port types: Lightning, Micro USB (Type-B)
USB-C
Charger
Voltage 17.6±0.1 V
Rated Power 60 W
Intelligent Flight Battery
Capacity 3850 mAh
Voltage 17.6 V (max)
15.4 V (typical)
Battery Type LiPo 4S
Energy 59.29 Wh
Net Weight Approx. 297 g
Charging Temperature
Range
41° to 104° F (5° to 40° C)
Max Charging Power 80 W
For more information, read the User Manual:
http://www.dji.com/mavic-2
※
This content is subject to change without prior notice.
