dji MAVIC 2 PRO Quick Start Guides

1
2
3
Ensure the control sticks are rmly mounted.
The remote controller cable with the Lightning connector is mounted by default. Use the
appropriate cable for your mobile device to connect to the remote controller. When using an
iPad or tablet, use the USB port on the remote controller.
Do not use the Micro USB and the USB ports simultaneously for linking video.
4. Preparing the Remote Controller
Unfold the antennas and mobile device clamps,
then attach the control sticks.
Place one end of the RC cable to the
end of the slot.
Attach your mobile device within the clamps.
Charging Time:
~2 hour 15 minutes
Set the antennas parallel to each other
Optimal Transmission Range
Strong
Weak

dji MAVIC 2 PRO Specifications

General

Type	Quadcopter
Backlight	Yes
Product color	Gray
Construction type	Ready-to-fly (RTF)
Maximum speed	20 m/s
Frequency band	2.400 - 2.483, 5.725 - 5.850 GHz
Number of axis	3
Number of rotors	4 rotors
Maximum tilt angle	35 °
Hovering time (max)	29 min
Maximum flight time	31 min
Maximum ascent speed	5 m/s
Maximum descent speed	3 m/s
Maximum weight capacity	- kg
Maximum wind resistance	10 m/s
Vertical hover accuracy	0.5 m
Horizontal hover accuracy	1.5 m
Maximum operating distance	8000 m
Maximum pitch angular velocity	200 °/sec
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160 pixels
Maximum frame rate	120 fps
Optical sensor size	1/1 \
Camera shutter speed	8 – 1/8000 s
Supported video modes	1080p, 2160p
Image formats supported	DNG, JPEG, RAW
Video formats supported	AVC, H.264, H.265, HEVC, MOV, MP4
Maximum image resolution	5472 x 3648 pixels
Maximum video resolution	3840 x 2160 pixels
Field of view (FOV) angle	77 °
Bitrate at maximum video resolution	100 Mbit/s
Operating temperature (T-T)	-10 - 40 °C
USB ports quantity	1
Operating frequency	2400 - 2483, 5725 - 5850 MHz
Maximum device width	160 mm
Output power	60 W
AC adapter power	80 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100 - 240 V
AC adapter output current	3.41 A
AC adapter output voltage	17.6 V
Equivalent Isotropically Radiated Power (EIRP)	26 dBmW
Internal memory	8 GB
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	128 GB
Built-in processor	-
Battery voltage	15.4 V
Battery capacity	3850 mAh
Transmitter battery capacity	3950 mAh
Moving control functions	Backward, Downward, Forward, Turn left, Turn right, Upward
Cables included	Lightning, Micro-USB, USB Type-C

Weight and Dimensions

Depth	322 mm
Width	242 mm
Height	84 mm
Weight	907 g
Battery weight	297 g
