9
EN
Thermal Camera (Mavic 3T)
Thermal Imager Uncooled VOx Microbolometer
Lens
DFOV: 61°
Focal Length: 9.1 mm (equivalent: 40 mm)
Aperture: f/1.0
Focus: 5 m to
∞
Infrared Temperature
Measurement Accuracy
±2° C or ±2% (using the larger value)
Intelligent Flight Battery
Capacity 5000 mAh
Standard Voltage 15.4 V
Max Charging Voltage 17.6 V
Battery Type LiPo 4S
Energy 77 Wh
Weight 335.5 g
Charging Temperature 5° to 40° C (41° to 104° F)
Battery Charger
Input 100-240 V AC, 50-60 Hz, 2.5 A
Output
Max. 100 W (Total)
When both ports are in use, the maximum output of
one of the ports is 82 W. The charger will dynamically
allocate the output of the two ports accordingly to
the power load.
Remote Controller (Model: RM510B)
Weight Approx. 680 g
Battery Li-ion (5000 mAh @ 7.2 V)
Storage Capacity ROM 64GB + expandable storage via microSD card
Operating Time 3 hrs
Operating Temperature -10° to 40° C (14° to 104° F)
Charging Temperature 5° to 40° C (41° to 104° F)
GNSS GPS + Galileo + GLONASS
O3 Enterprise
Operating Frequency 2.400-2.4835 GHz, 5.725-5.850 GHz*
Max Transmission
Distance
(Unobstructed, free of
interference)
15 km (FCC), 8 km (CE/SRRC/MIC)
Max Transmission
Distance**
(with interference)
Strong Interference (urban landscape, limited line of
sight, many competing signals):
1.5-3 km (FCC/CE/SRRC/MIC)
Medium Interference (suburban landscape, open line
of sight, some competing signals):
3-9 km (FCC), 3-6 km (CE/SRRC/MIC)
Weak Interference (open landscape, abundant line of
sight, few competing signals):
9-15 km (FCC), 6-8 km (CE/SRRC/MIC)
