dji MAVIC 3T Quick Start Guide

Remote Controller
The DJI RC Pro Enterprise remote controller features O3 Enterprise, the latest version of DJI’s
signature OCUSYNC
TM
image transmission technology, and can transmit a live HD view from the
camera of an aircraft at a distance of up to 15 km*. The remote controller comes with a wide range of
aircraft and gimbal controls as well as customizable buttons. The built-in microphone allows recording
voice and 5.5-in high brightness 1000 cd/m
2
screen boasts a resolution of 1920×1080 pixels. Users
can connect to the internet via Wi-Fi and the Android operating system comes with a variety of
functions such as Bluetooth and GNSS.
1. Control Sticks
2. Back/Function Button
3. RTH Button
4. Flight Pause Button
5. Flight Mode Switch
6. 5D Button
7. Power Button
8. Confirm Button/Customizable C3
Button
9. Touchscreen
10. M4 Screw Hole
11. microSD Card Slot
12. USB-C Port
13. Mini HDMI Port
14. Microphone
15. Gimbal Dial
16. Record Button
17. Antennas
18. Status LED
19. Battery Level LEDs
20. Focus/Shutter Button
21. Camera Settings Dial
22. Air Vent
23. Control Sticks Storage Slot
24. Customizable C1 Button
25. Speaker
26. Customizable C2 Button
27. Air Intake
* The remote controller is able to reach its maximum transmission distance (FCC) in a wide-open area
with no electromagnetic interference at an altitude of about 400 ft (120 m).

dji MAVIC 3T Specifications

General

Built-in processor	-
Internal memory	64 GB
Memory card slot(s)	Yes
Compatible memory cards	MicroSD (TransFlash)
AC adapter power	100 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100/240 V
AC adapter output current	2.5 A
Operating temperature (T-T)	-10 - 40 °C
Moving control functions	Backward, Downward, Forward, Upward
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Optical sensor size	1/2 \
Camera shutter speed	8-1/8000 s
Video formats supported	AVC, H.264, H.265, HEVC, MPEG4
Maximum image resolution	5280 x 3956 pixels
Field of view (FOV) angle	85 °
Supported video streaming modes	1080p
Battery voltage	7.2 V
Battery capacity	5000 mAh
Type	Quadcopter
Product color	Gray
USB ports quantity	1
Maximum speed	6 m/s
Frequency band	2.4 - 2.4835 GHz
Number of rotors	4 rotors
Maximum tilt angle	35 °
Hovering time (max)	45 min
Maximum ascent speed	1 m/s
Maximum weight capacity	- kg
Maximum wind resistance	12 m/s
Maximum operating distance	32000 m
Maximum yaw angular velocity	200 °/sec
