dji MAVIC 3T Quick Start Guide

Mavic 3T Wide Camera
Sensor
1/2" CMOS; Effective pixels: 48M
Lens
FOV: 84°
Format Equivalent: 24 mm
Aperture: f/2.8
Focus 1 m to ∞
Mavic 3T Thermal Camera
Thermal Imager
Uncooled VOx Microbolometer
Lens
DFOV: 61°
Focal Length: 9.1 mm (equivalent: 40 mm)
Aperture: f/1.0
Focus: 5 m to ∞
Infrared Temperature
Measurement Accuracy
±2° C or ±2% (using the larger value)
Intelligent Flight Battery
Capacity
5000 mAh
Standard Voltage
15.4 V
Max Charging Voltage
17.6 V
Battery Type
LiPo 4S
Energy
77 Wh
Weight
335.5 g
Charging Temperature
5° to 40° C (41° to 104° F)
Battery Charger
Input
100-240 V AC, 50-60 Hz, 2.5 A
Output
Max. 100W (Total)
When both the ports are used, the maximum output power of each
interface is 82 W, and the charger will dynamically allocate the
output power of the two ports according to the load power.
Remote Controller (Model: RC510B)
Weight
Approx. 680 g
Battery
Li-ion (5000 mAh @ 7.2 V)
Storage Capacity
ROM 64GB + expandable storage via microSD card
Operating Time
3 hours
Operating Temperature
-10° to 40° C (14° to 104° F)
Charging Temperature
5° to 40° C (41° to 104° F)
GNSS
GPS + Galileo + GLONASS
O3 Enterprise
Operating Frequency
2.400-2.4835 GHz, 5.725-5.850 GHz
*
Max Transmission Distance
(Unobstructed, free of
interference)
15 km (FCC), 8 km (CE/SRRC/MIC)
Max Transmission Distance
Strong Interference (urban landscape, limited line of sight, many

dji MAVIC 3T Specifications

General

Built-in processor	-
Internal memory	64 GB
Memory card slot(s)	Yes
Compatible memory cards	MicroSD (TransFlash)
AC adapter power	100 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100/240 V
AC adapter output current	2.5 A
Operating temperature (T-T)	-10 - 40 °C
Moving control functions	Backward, Downward, Forward, Upward
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Optical sensor size	1/2 \
Camera shutter speed	8-1/8000 s
Video formats supported	AVC, H.264, H.265, HEVC, MPEG4
Maximum image resolution	5280 x 3956 pixels
Field of view (FOV) angle	85 °
Supported video streaming modes	1080p
Battery voltage	7.2 V
Battery capacity	5000 mAh
Type	Quadcopter
Product color	Gray
USB ports quantity	1
Maximum speed	6 m/s
Frequency band	2.4 - 2.4835 GHz
Number of rotors	4 rotors
Maximum tilt angle	35 °
Hovering time (max)	45 min
Maximum ascent speed	1 m/s
Maximum weight capacity	- kg
Maximum wind resistance	12 m/s
Maximum operating distance	32000 m
Maximum yaw angular velocity	200 °/sec
