dji PHANTOM 3 Advanced Manual

DJI Phantom 3 Advanced Manual
Last updated March 27 2020 Page 7 of 16
The drone will automatically launch itself and start flying according to the flight plan. When it has
finished, it will return to the home point and land. You can also abort the mission (for example when
you see it might hit something or someone) by hitting the ‘home’ button next to the power button on
the controller. To ensure a safe landing, it is preferred that you do not let the drone land all by itself
but that you “catch” it from the air. This is done as follows:
When the drone is hovering above the home point and starting its descend, control the descend by
steering in the opposite direction. In other words: the drone is automatically landing by flying down
and you want to steer it back up so you can control the speed of the landing. If you steer up as much
as it is going down, it will hover (see explanation and figure below). The goal is to make it hover just
above the person who will catch it (see figure). Pro tip: make sure you are standing with your back to
the sun so you have no trouble seeing the drone when you manually fly it or try to catch it.
From left to right: controlled descend, hovering in the air within reach of your colleague and
catching the drone. The drone is represented by the red shape.
Blue arrow: the drone goes UP
Red arrow: the drone goes DOWN
Yellow
arrow: the drone goes to the LEFT
Green
arrow: the drone goes to the RIGHT

dji PHANTOM 3 Specifications

General

Max Flight Time	23 minutes
Battery Capacity	4480 mAh
Weight	1280 g (Including battery and propellers)
Max Ascent Speed	5 m/s
Max Descent Speed	3 m/s
Max Service Ceiling Above Sea Level	6000 m
GPS Mode	GPS/GLONASS
Battery Voltage	15.2 V
Battery Type	LiPo 4S
Max Charging Power	100 W
Lens FOV	94°
Aperture	f/2.8
Shutter Speed	8s -1/8000s
Max Image Resolution	4000 x 3000
Max Bitrate	40 Mbps
Max Speed	16 m/s (ATTI mode, no wind)
Video Resolution	2.7K: 2704x1520p 24/25/30 (29.97); FHD: 1920x1080p 24/25/30/48/50/60
Operating Temperature	0°C to 40°C
Transmitter Power (EIRP)	20 dBm (FCC), 14 dBm (CE)
Video Recording Modes	2.7K, FHD
Camera Sensor	1/2.3" CMOS
ISO Range	100-3200 (video), 100-1600 (photo)
Photo Formats	JPEG, DNG
Video Formats	MP4/MOV (H.264)
Remote Controller Operating Frequency	2.4 GHz
Mobile Device Holder	For mobile phones or tablets
Hover Accuracy Range	Vertical: +/- 0.5 m; Horizontal: +/- 1.5 m
