dji PHANTOM 4 ADVANCED User Manual

Aircraft
32
©
2017 DJI All Rights Reserved.
Phantom 4 Advanced / Advanced+ User Manual
Using the Battery
LED1
LED2
Battery Level Indicators
LED3
LED4
Power Button (Built-in LED)
Turning ON/OFF
Turning On:
Press the Power Button once, then press again and hold for 2 seconds to turn on. The
Power LED will turn green and the Battery Level Indicators will display the current battery
level.
Turning
Off: Press the Power Button once, then press again and hold for 2 seconds to turn off. The
battery power LED will flash when powering off the Phantom to allow automatically
stopping of a recording during the event recording wasn’t stopped.
Checking the Battery Level
The Battery Level Indicators display how much power remains. When the battery is turned off, press
the Power Button once. The Battery Level Indicators will light up to display the current battery level.
See below for details.
The Battery Level Indicators will also show the current battery level during charging and
discharging. The indicators are dened below.
: LED is on. : LED is ashing.
: LED is off.
Battery Level Indicators
LED1 LED2 LED3 LED4 Battery Level
87.5%~100%
75%~87.5%
62.5%~75%
50%~62.5%
37.5%~50%
25%~37.5%
12.5%~25%
0%~12.5%
=0%

dji PHANTOM 4 ADVANCED Specifications

General

Camera Sensor	1-inch CMOS
Effective Pixels	20 MP
Max Flight Time	30 minutes
Weight	1388 g
Max Ascent Speed	6 m/s (Sport mode)
Max Descent Speed	4 m/s (Sport mode)
GPS Mode	GPS/GLONASS
Video Storage Bitrate	100 Mbps
Photo Format	JPEG, DNG (RAW)
Battery Capacity	5870 mAh
Battery Voltage	15.2 V
Battery Type	LiPo 4S
Battery Energy	89.2 Wh
Gimbal	3-axis (pitch, roll, yaw)
Max Speed	72 kph (Sport mode)
Transmission Range	7 km
Operating Temperature Range	0° to 40°C (32° to 104°F)
Lens	24mm f/2.8
Supported File Systems	FAT32/exFAT
Video Format	MP4/MOV (H.264/MPEG-4 AVC)
Remote Controller Operating Frequency	2.400 GHz to 2.483 GHz, 5.725 GHz to 5.825 GHz
Remote Controller Max Transmission Distance	7 km
Video Resolution	4K 60fps
