Preparation
1. Charging the Battery
1
2
3
100-240 V
50-60 Hz
Charging Time: Approx. 1 hour and 30 min.
Charge the battery to bring it out of hibernation
before using for the rst time.
2. Preparing the Screwdriver
The package includes a screwdriver handle and two
bits. The #1 bit is used with screw box A. The smaller
end is for T2 screws, while the larger end is for the
other screws in screw box A. The #2 bit is used with
screw box B. The smaller end is for all the screws in
screw box B, while the larger end is not used. Make
sure to use the screws with a suitable bit.
Follow the instructions for cable connection and
wiring to avoid cable damage.
4. Cable Connection Instructions
Connect the black, orange, and red cables to the
ports with the corresponding color.
3. Legend
Indicates that the bottom of the
robot is displayed.
Refers to the accessories required
including such information as the
screw model and quantity. For
example, the description in this
illustration indicates that six screws
of the M3-A model are required.
(M3-A)
×6
Refers to where the required
accessories are located in the screw
box.
A #1 #2 B
