123
detects high and low electrical levels.
Trigger
Infrared
obstacle
avoidance
sensor
VCC(5V)
GND
OUT(TTL)
High or low
electrical level
Vibration
sensor
VCC(5V)
GND
OUT(TTL)
High or low
electrical level
Tilt sensor
VCC(5V)
GND
OUT(TTL)
High or low
electrical level
Sound sensor
VCC(5V)
GND
OUT(TTL)
High or low
electrical level
Disk encoding
technology
VCC(5V)
GND
OUT(TTL)
High or low
electrical level
Touch sensor
VCC(5V)
GND
OUT(TTL)
High or low
electrical level
(1) Description: Returns "True" when the I/O pin level of the specified port of the specified sensor Adaptor
