Zenmuse H20
Series
User Manual
©
2020 DJI All Rights Reserved.
13
Black Hot
The opposite to White Hot, using black for warmer objects and white for cooler
objects. The heat distribution of high temperature targets can be better observed
when outdoors.
Different palettes applied to the same example image are shown below.
White Hot Black Hot
Iron Red Rainbow 1
Isotherm
This feature allows designated temperature ranges to be represented with different color
schemes, so that objects within this range impart higher contrast and better visibility.
The temperature range is set by upper and lower thresholds.
Hot Iron Isotherm Fulgurite Isotherm
